SerialGate User Guide
66
Product Specification
Communication
Ethernet Port 2 ports of 10/100Mbps RJ-45
Assigning
IP Address
Static, Dynamic
Number of Serial
Ports
16 Ports (RS-232/RS-422/485)
Serial Speed Maximum 921.6kbps
Hardware
Process 400MHz
Flash Memory 8MByte
SDRAM 32MByte
Power AC : 100 ~ 245 VAC
Size 430(W) x 193(L) x 45(H)mm
Weight 2,480g
Operation
Temperature
0 ~ 50 °C
Serial Port
Signal
TX, RX, DTR, DSR, CTS, RTS, DCD
Humidity Max 95% R.H
LED Power ,Serial ,Ready, Link
Serial Port
Protection
± 15kV ESD Protection
SD/MMC CARD SD Support (Maximum 32GB)
Reset Button
Feature Action Result
Warm Booting Press for less than 3 sec. SerialGate reboots
Factory Default Press for more than 3 sec. Restores the default setting
