SerialGate User Guide
54
Testing WAN Port
Test WAN port in a device server.
For the test, WAN port must be connected to network, and there should be a PC with the IP address,
‘192.168.0.1’ for the Ping test on network.
If a user selects ‘yes’ option, it tries Ping to ‘192.168.0.1’, and prints out the result on LCD.
T e s t I n g W A N P o r t
OK !
If there is nothing wrong, it sh
ows ‘OK !’; otherwise ‘Failed !’.
Testing LAN Port
Test LAN port of a device server.
For the test, LAN port must be connected to network, and there should be a PC with the IP address,
‘192.168.0.1’ for the Ping test on network.
If a user selects ‘yes’ option, it tries Ping to ‘192.168.0.1’, and prints out the result on LCD.
T e s t I n g L A N P o r t
OK !
If there is nothing wrong, it shows ‘OK !’; otherwise ‘Failed !’.
Testing MMC
It tests whether memory card of a device server can read and write.
For the test, SD card must be inserted to the device server.
If a user selects ‘yes’ option, it reads and writes the data on SD card, and prints out the result on LCD.
T e s t I n g M M C
OK !
If there is nothing wrong, it shows ‘OK !’; otherwise ‘Failed !’.
