Solvline SG-1160 - Manual (Page 19)

SerialGate User Guide
19
Serial Console Port
The SG-1160 supports console port. Connect
to the console port from the PC with a serial
cable. Run a utility such as HyperTerminal,
with following settings: 115200 bps, None
Parity, 8 Data bits, 1 Stop Bit. This will allow
the users to connect to a device.
Connection using the PortView
By running the PortView program in the Utility
and Documents CD included in the SerialGate
package, you can dynamically search all
SerialGates on the network and connect to
any of them. (For more information on
PortView, please refer to the PortView manual
in the Utility and Documents CD included in
the SerialGate package)
After running PortView, click Search button. You can view the list that is running in your network. Select
the module that you would make a connection to, and click Telnet or Web to connect to the device via
Telnet or Web, respectively.
You can modify and apply the IP address of SerialGate using this program.
Now, you are ready to connect to SerialGate! There are three options to configure SerialGate.
1) Configuration via Web Browser
The users can easily configure SerialGate with web interface, accessible from most web browser. For
more information, please refer to Chapter 5. Configuration from Web Browser.
2) Configuration via Telnet
The users can configure SerialGate with commands after accessing SerialGate through Telnet. For more
information, please refer to Chapter 6. Configuration via Telnet.
3) Configuration via PortView
The users can use a Windows-based utility PortView from SystemBase to monitor SerialGate. For more
information on using the utility for your administration purpose, please refer to PortView User Guide.
