SerialGate User Guide
50
Data Bits 5 ~ 8 8
Stop Bits 1, 2 1
Latency_time 0 ~ 65535 0 <<: Increase the value of the cursor
position.
>>: Move cursor to the next space.
Enter: Save the current option, and go to
the next menu.
Keepalive 0 ~ 65535 0
Remote IP 0.0.0.0
Remote Port 4000
Termination Enable, Disable Disable
<<, >> : Select option
Enter: Save the current option, and go to
the next menu.
Status
Check the connection status of the port and devi ce server’s version information.
In order to select Status, press ‘ESC’ on the panel until ‘Main Menu’ comes up, and if ‘Main Manu’ is
displayed, press ‘<<’ or ‘>>’ until you see ‘Status’. Then, press ‘Enter’ to change the details.
Press ‘ESC’ at any time to moves to the top menu.
Menu Display Description
Version L10b, K10a, F10a
B : Boot_loader Version
O : OS Version
F : Firmware Version
Port Status - - - - - - - - - - - - - - - -
If serial port is in communication, the port
number is displayed on the corresponding
space. Since it only shows one digit, it will
display 0 ~ 6 for port 10 ~ 16.
