SerialGate User Guide
17
Chapter 4. How to Connect
This chapter explains how to install SerialGate. It deals with LAN and serial connection guides for
SerialGate to operate together with the target serial device.
Connection Guide
In order to connect SerialGate to network, you need to use RJ45 Ethernet port. It supports both
10Mbps and 100Mbps Ethernet connection (auto-sensing). Since WAN/LAN port supports MDIX,
it automatically detects any kind of cable. (Cross or direct LAN cable) Plug one end of a LAN
cable to SerialGate and the other end to a hub, switch, or any other network device.
Powering On for the First Time
First of all, please make sure that the power input you supply to the module is corresponding with the
SerialGate model that you have. If an appropriate power input has been successfully supplied,
SerialGate will power on and start booting.
Although there is no power LED to check the status, you can check by LEDs on the RJ45 Ethernet port.
LED status operation is described in Chapter 3. Hardware Description.
An IP address is required to access web interface in SerialGate or telnet command-line configuration
tool. By factory default, a static IP address is assigned to SerialGate. After the initial connection, you can
either manually assign a different IP address or set SerialGate to automatically get an IP address from a
DHCP server. While this depends on your network environment and policy, it is strongly recommended
that a user assigns SerialGate with a unique static IP.
