SerialGate User Guide
52
(*) When a user performs this test, all the programs running in the device server stops. Therefore, the
user must restart the device server after the test.
Menu Option Default Description
RS232(Loopback)
Cancel Yes Cancel
<<, >>: Select option.
Enter: If Cancel selected, go to the next menu. If
Yes is selected, that action is performed.
RS232(Signal)
RS422(Loopback)
RS485(Loopback)
Testing WAN Port
Testing LAN Port
Testing MMC
Testing Reset
Testing Console
Testing RTC
RS232 (Loopback)
Change all the serial ports of a device server to RS-232, and conduct a Loopback test.
RS-232 Loopback connector must be connected to all the serial ports for the test.
If a user selects ‘yes’ option, it starts Loopback test and prints out the result on LCD.
T e s t I n g ( R S 2 3 2 )
O O O O O O O O O O O O O O O O
If there is nothing wrong, it displays ‘O’; otherwise ‘X’.
