4 INDIRECT FIRED WATER TANK
III TANK SPECIFICATIONS
A
C
D
E
F
H
G
B
A-TANK TOP
B-TEMP. & PRESS. RELIEF VALVE
C-DOMESTIC HOT WATER OUTLET
D-RECIRCULATION(HWT-80)
E-BOILER WATER INLET(SUPPLY)
F-CONTROL
G-DOMESTIC COLD WATER INLET
H-BOILER WATER OUTLET(RETURN)
KEY
TANK JACKET
INSULATION
MODELS: HWT-40, HWT-60, HWT-80
MODEL
DIAM.
OF TANK
VOLUME
(Gallons)
HEIGHT TO CONNECTION (Inches) COIL
SURFACE
(Sq. Ft.)
WEIGHT (Lbs.)
A B C D E F G H NET SHIPPING FILLED
HWT-40
HWT-60
HWT-80
HWT-120
20"
20"
22"
28"
40
55
79
119
45
58
71
68
37-1/4
49-5/8
61-1/2
58-1/4
35-5/8
48
61-1/4
68
N/A
N/A
47-7/8
48-7/16
35
35
54-5/8
42
20
20
40-1/4
33-7/8
10-7/16
10-7/16
10-7/8
13
8-7/8
8-7/8
10-1/4
8-7/8
14
14
26
26
116
118
232
333
124
143
243
355
449
576
737
1324
PHYSICAL SPECIFICATIONS
CONNECTIONS
NOTES:
1. All fittings are female NPT thread connections, except for domestic hot and cold on the HWT-120.
2. HWT-120 supplied with adapter to increase from 1" male to 1-1/4" female, for domestic hot and cold.
3. HWT-120 has inspection port (with access near bottom of tank for removal of any sediment buildup).
DESCRIPTION
MODEL
HWT-40 HWT-60 HWT-80 HWT-120
TEMP. & PRESS. RELIEF VALVE
DOMESTIC HOT WATER OUTLET
DOMESTIC COLD WATER INLET
BOILER WATER OUTLET (RETURN)
CONTROL
BOILER WATER INLET (SUPPLY)
RECIRCULATON (HWT-80
3/4"
3/4"
3/4"
1"
1/2"
1"
–
3/4"
3/4"
3/4"
1"
1/2"
1"
–
1"
1"
1"
1"
1/2"
1"
3/4"
1"
1" MPT
1" MPT
1"
1/2"
1"
3/4"
HWT-120
