54711 3-1
Section 3
Installation
3.1 Mounting the Cabinet
Read the environmental specifications in Section 2.1 before mounting the SK-FFT
cabinet. This will ensure that you select a suitable location.
The cabinet can be surface or flush mounted. Do NOT flush-mount in a wall designed
as a fire break.
3.1.1 Surface Mounting
The Cabinet can be mounted on the wall surface by using the mounting holes in the
back of the cabinet (see Figure 3-1).
1. Insert two screws level with each other, 14" apart for the top cabinet key shaped
holes. See Figure 3-1.
2. Hang the cabinet onto the two screws. Tighten the screws down.
3. Insert two screws into the two bottom mounting holes and tighten them snug to the
cabinet.
Figure 3-1 Cabinet Mounting Holes
Bottom Mounting Holes
20"
26 -½ ”
Key Shaped Holes
