SeaLand TankWatch 4 Level Monitoring System - Manual (Page 3)

3
PRODuCT SPECIfICATIONS
Product Name: TankWatch ® 4 Level Monitor System
Electrical:
12 Volts DC @ .017 amps (without optional relay) and .152 amps (with optional relay)
24 Volts DC @ .014 amps (without optional relay) and .072 amps (with optional relay)
Float Switch Rating = 20 watts with resistive load
12-pin terminal block allows up to one 12-gauge wire per position
Maximum Tank Pressure: 25 PSI
Materials:
DIMENSIONAL SPECIfICATIONS
Minimum Clearance
(Behind Wall)
* Max length for 45-inch probes
is 43 3/4-in. (1111mm).
Electrical and dimensional specifications subject to change without notice.
Float . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Buna N
Tank-mounted Float Switch Cap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PVC
Float Switch Body. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ABS
O-Rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nitrile
Adjustable Stems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cross Linked Polypropylene
Compression Nut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Glass Reinforced Polypropylene
Control Panel Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Polypropylene
Face Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Polycarbonate
4 3/4"
[2mm]
*
