2
TAbLE Of CONTENTS
SAfETY INSTRuCTIONS
WARNING: When using this device, always exercise basic safety precautions, including the following:
•
Read all instructions before installation or use.
• Never connect this device to any electrical circuit with other than 2 or 24 volt Direct Current or exceed
the amperage draw listed below.
•
Never install the indicator panel in an atmosphere with potentially flammable or explosive vapors.
• Never install the probe cap with float switches into a tank that contains anything other than fresh, gray or
black water.
CAuTION: Dropping or rough handling of float switches may result in damage.
PRODuCT fEATuRES
• Eliminates false reading from fouled probes.
• Three float switches, four level indications for all tanks up to 22-inch (559mm) and 45-inch (114cm) in depth.
• Deluxe panel complements bathroom decor and provides international symbology.
• Installs in any rigid tank with optional 3-inch NPT mounting flange.
• One model operates on 2 or 24 VDC.
• Probe cap provides clean-out fitting for easy access to interior of tank.
• Cap is available with or without 5/8" vent hose connection.
• Optional shut-off relay plugs into back of circuit board to shut down toilet or water system when gray or
black water tank is full or when freshwater tank is empty.
•
Always one level light on to confirm that electrical power is applied.
• Only one level light on at a time to eliminate confusion and save battery power.
• CE and IMCI approved for electromagnetic compatibility.
The TankWatch 4 Level Monitor System is designed to permit remote sensing of liquid levels in wastewater,
gray water or potable fresh water tanks. The TankWatch 4 utilizes three micro-float switches, which activate a
four-light panel. One is fixed and activates a full light when the liquid is within approximately 2-inches of the top
inside surface of the tank. The other two float switches are mounted on adjustable stems and can be posi-
tioned to within 2-inches of the bottom of the tank. The stems are semi-flexible and are designed to flex with
the sloshing of the tank contents. A simple procedure allows one adjustable stem to sense when the tank is
empty and the other adjustable stem to sense when the tank is 1/4 or 1/2 full, depending on the application.
MODELS AND ACCESSORIES
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . 2
Product Features. . . . . . . . . . . . . . . . . . . . . . . . . 2
Models and Accessories . . . . . . . . . . . . . . . . . . . 2
Dimensional Specifications . . . . . . . . . . . . . . . . . 3
Product Specifications. . . . . . . . . . . . . . . . . . . . . 3
Installation Instructions . . . . . . . . . . . . . . . . . 4 - 5
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . 6
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Manufacturer’s One-Year Limited Warranty . . . . 8
Control Panel Mounting Template
336003
336004
313600115
336006
307230272
60034292
600342490
385318714
36060022
360600224
TankWatch ® 4 Panel and Cap with Vent, 22-inch Probes
TankWatch ® 4 Panel and Cap without Vent, 22-inch Probes
TankWatch ® 4 Panel and Cap with Vent, 45-inch Probes
TankWatch ® 4 Panel and Cap without Vent, 45-inch Probes
Universal Flange (3-inch NPT) with gasket and stainless steel hardware
Plug In Relay, 2VDC
Plug In Relay, 24VDC
“Do Not Flush” Panel
TankWatch ® 4 Panel with 2VDC Relay
TankWatch ® 4 Panel with 24VDC Relay
Part Number Description
