13

Figure 3. typical Single Stage Heat / Cool thermostat Connection

BLOWER

MOTOR

GND

TO FIELD
SUPPLIED DISCONNECT

SINGLE STAGE

HEAT/COOL THERMOSTAT

OUTDOOR

SECTION

FREEZESTAT

AIR HANDLER SECTION

TERMINAL

BOARD

G

C

W2

W1

O

Y

R

C

Y

R

R

C G Y

W

L1

L2

L3

NOTE: C &W2 can be connected to optional electric heat.

See

Note

BLACK

BLACK

BROWN

GREEN

OPTIONAL

FIELD

SUPPLIED

WIRING
