REDLINK BRIDGE OPERATION GUIDE
955-0064, REV-B | 18
5. After the LEDs stop flashing, press the Iris Limit and Focus Limit buttons to set the new channel:
‒ Iris Limit button: Press to set the tens.
‒ Focus Limit button: Press to set the ones.
For example, if you want the channel to be 14, press the Iris Limit button once, and then press the Focus
Limit four times.
6. Wait a few seconds, and the Iris Limit and Focus Limit LEDs flash to tell you what the new channel is.
7. Power off the T.H.C. by toggling the power switch to Cable mode.
8. Power on the T.H.C. by toggling the power switch to Battery mode.
The Wireless LED remains solid blue once it connects to the channel.
9. In the DSMC menu, go to Menu > Settings > Setup > Motor Control.
10. Select the Wireless tab.
11. Select the Enable Wireless Controller check box.
12. Select the channel from the Channel drop-down menu. The default is Channel 1, and you can select one
out of 42 channels.
13. Select the strength of the wireless signal from the Power drop-down menu:
‒ Low: The low power setting balances range and low power and is appropriate in most cases.
‒ High: For maximum range, the high power setting can be used.
NOTE: Be sure to set wireless signal power appropriately. If the wireless signal power is set to High, the T.H.C.
may not perform as desired or may lose connection if operating in close proximity to the REDLINK Bridge.
When using the High setting, the T.H.C. should be at least one (1) meter from the REDLINK Bridge for
proper operation.
Set Channel with Limit Buttons
