6
Fire Alarm Training • 8700055 • Rev F • 4/10
Symbols for Control Panels
Symbol Description
Control panel-basic shape
Fire alarm control panel
Fire systems annunciator alarm
Annunciator panel-from NECA 100, symbol 7.006
Fire alarm transponder or transmitter
Elevator status/recall
Fire alarm communicator
Fire system control panel
Halon
Carbon dioxide
Dry chemical
Foam
Wet chemical
Clean agent
Water mist
Deluge sprinkler
Control panel for heating, ventilation, air conditioning, exhaust stairwell pressurization, or similar equipment
Remote MIC for voice evacuation system
Voice evacuation panel-from NECA 100, symbol 7.008
Fire alarm terminal cabinet-from NECA 100, symbol 7.009
Fire command system
Fire alarm control unit
Sprinkler alarm panel
Relay alarm panel
Data gathering panel
Amplifier rack
HL
FACP
FSA
FAA
FTR
ESR
FAC
FSCP
FSCP
FSCP
CO
2
DC
FSCP
FO
FSCP
WC
FSCP
CA
FSCP
WM
FSCP
DL
FSCP
HVA
MIC
EVAC
FATC
FCS
FACU
SAP
RP
DGP
AMP
