NORAC UC4+BC+JD8A - Manual (Page 7)

3
Item Part Number Name Quantity
H70 44865-38 HYDRAULICS FITTING KIT - ACTIVE ROLL 1
H71 44864-04 HOSE ASSEMBLY 122R2-08 168 IN L 6FORX 12FORX 1
H72 44862-11 HOSE ASSEMBLY 122R2-04 60 IN L 4FORX 4FORX 2
H75 105480 HYD CYLINDER ROLL BIAS 1.75IN BORE X 7.125IN STROKE (6 SAE PORTS) REV C 1
H78 44864-03 HOSE ASSEMBLY 122R2-08 166 IN L 6FORX 6FORX
1
M01 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL 1
M10 UC4+BC+JD8A-INST MANUAL INSTALLATION UC4+ JOHN DEERE 30 SERIES W ACTIVE ROLL AND PROP ML
1
M70 100660 BOLT HEX NC GR5 PLTD 1/4X1
1
M71 100871 NUT LOCK NYLON NC PLTD 1/4 IN
1
V01 44960D VALVE BLOCK ASSEMBLY 3 STATION CC/LS PROP DT 4 BOLT
1
V70 44962D VALVE BLOCK ASSEMBLY EXPANSION DPOC PROP DT 4 BOLT
1
* For systems purchased BEFORE October 1, 2011, the roll sensor part number is 44641.
