Lay one of the posts on the ground and insert the bottom
rail and the three vertical spindles as shown aside.
Note that the longer spindle should be in the middle of
the three.
Insert the seven horizontal spindles as shown aside.
Make sure to weave the spindles as they are being
inserted into the post.
Continue assembly by inserting the top arched rail end
into the post and progressively into each of the vertical
spindles.
Proceed to attach the second post to the trellis assembly
as shown below.
1
2
3
4
S T E P O N E
NOTE: There are locking tabs located at the ends of the
horizontal rails. Once inserted and pushed into the routed
holes, they will lock into place.
1
2
3
4
1915 Dove St., Port Huron MI USA 48060
Toll Free Phone: 1 800 282 9346 Toll Free Fax: 1 877 464 9286
Short Spindle
Short Spindle
Long Spindle
