New England Arbors VA80240 - Manual

Check Box for These Contents
In the event of missing or defective parts please call our customer service dept.
at 1 800 282 9346, ext #20 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
1. 4 x 4 x 30” Post Extensions (4)
2. #8 x 1 1/2“ Stainless Steel Screws (32)
3. Vinyl Weld (1)
Tools You Will Need
• Cordless Drill
General Information
• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
• We recommend an area approx 5’x 8’ for unobstructed assembling.
• You should not need to use excessive force when assembling components.
The 4x4 Professional Post Extension Kit
Please read through before starting assembly.
ASSEMBLY INSTRUCTIONS
1
1
2
(Designed to be used with any New England Arbor with 4x4 Posts)
Not to Scale
30
4
4
8
2
3
VinylWeld
Glue all four sides of the joiner
(60 second cure time).
STEP ONE STEP T WO
Slide the joiner of the 4x4 extension
into the arbor posts.
1915 Dove St., Port Huron MI USA 48060
Toll Free Phone: 1 800 282 9346 Toll Free Fax: 1 877 464 9286
www.newenglandarbors.com
VinylWeld
STEP THREE
Screw all four sides of the arbor posts
with 2 screws per side (repeat for all posts).
* Once arbor installation is complete, the extension
joint should be buried 1" to 3" (depending on the
arbor it is being used with), below earth grade.
*
