New England Arbors VA54230 - Manual

Check Box for These Contents
In the event of missing or defective parts please call our customer service department at 1 800 282 9346, ext #20
(Mon. to Fri. 8:00 AM to 4:00 PM EST)
.
1. Keystone (1)
2. Arches (2)
3. Spindles - Short (2)
4. Spindles - Long (2)
5. Top Rail (1)
6. Posts (2)
7. Middle Rails (3)
8. Vertical Spindles (5)
9. Bottom Rail (1)
10. 1 1/2” Self-Auguring Stainless Steel Screw (8)
Tools You Will Need
• Cordless Drill
• Tape Measure
• Level
• Shovel
General Information
• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box)
to avoid scratching.
• We recommend an area approx 5’x 8’ for unobstructed assembling.
• You should not need to use excessive force when assembling component.
Hanover Trellis
Please read through before starting assembly.
A S S E M B LY I N S T R U C T I O N S
1
10
Not to Scale
IMPORTANT: CHECK THE INSIDE OF YOUR POSTS FOR ALL MATERIALS.
Ver 2.0/012514
✁ ✂ ✄ ☎ ✆
5
1
4
2
6
www.newenglandarbors.com
7
3
9
8
✝ ✝ ✞ ✟ ✠ ✡ ☎
✞ ☛ ✡ ☎
✞ ✝ ✡ ☎ ✞ ☞ ✟ ✌ ✡ ☎
