New England Arbors VA68202 - Manual (Page 2)

2
www.edenarbors.com
1
Lay one of the posts on the ground and insert the bottom
rail and the five horizontal spindles as shown aside.
Note that the bottom and top rails are different - the bottom
rail only has one side with routed holes.
Insert the five vertical spindles as shown aside. Make sure
to weave the spindles as they are being inserted.
Please note that there is one spindle with a ‘spear head’
and should be placed in the middle.
Continue assembly by inserting the top rail end into the
post and progressively into each of the vertical spindles.
proceed to attach the second post to the trellis assembly
as shown below. Ensure tabs are inserted all the way into
the post.
Insert the top arches into the keystones as shown.
Note that there is a sticker on each of the arches indicating
the top of the arch.
Fasten the keystones to the arches using the eight screws
provided.
1
2
3
4
S T E P O N E
2
3
NOTE: There are locking tabs located at the ends of the
horizontal rails. Once inserted and pushed into the routed
holes, they will lock into place.
4
5
5
Bottom rail
Spear Head
Insert 1st
Sticker
