Check Boxes (Total of 6) for These Contents
In the event of missing or defective parts please call our customer service
dept. at 1 800 282 9346, ext #20 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
1. Main Column Bottoms (4)
2. Main Column Tops (4)
3. Beam & Rafter Joiners (8)
4. One Way 4”x4” Internal Wood Post Guide (4)
5. Shade Slat Joiners (14)
6. Post Caps (4)
7. Post Trims (8)
8. Rafter & Beam Decorative End Caps (16)
9. Rafter Brackets (8)
10. Shade Slat Decorative End Caps (28)
11. Main Support Beams (4)
12. Rafters (12)
13. Shade Slats (28)
14. Rafter Hanger (6)*
(*) May be disposed of when installing
the Regency Pergola.
Regency Pergola Materials Breakdown
5 12 x 12 Flat Top Pergola
1
Not to Scale
2 6
7
3
8
4
9
5
11
12
13
14
