Mytek DIO MADI Card – User Manual
Quick Start
1. Installation of DIO MADI card
Remove the top cover from the converter,
unscrew the DIOCARD1 or DIOCARD2 slot plate
and install the DIO MADI card using the existing
screws. Double check if all the connector pins
match properly with the pins of the connector on
the main converter board.
2. Operation
The card is ready for operation immediately after
installing it in the converter.
3. Configuration
After turning on the 8x192ADDA converter you
should select the settings appropriate for your
configuration needed on the front panel. The DIO
MADI card should be connected to another
MADI device by one of three cables: optical, BNC
or FireWire.
Remember to turn
off and disconnect
power and signal
cables while working
with the top cover
removed.
Page: 5/24
