Mytek DIO MADI Card – User Manual
5.
Carefully insert new memory chip in the socket.
The chip slot (pin1) should be matching the socket
slot i.e. must be facing back of the unit. If
necessary gently manually bend pins inward, to
match the holes in the slot.
6. Mount the top cover back.
During installation
check correct chip
orientation.
