Mytek DIO MADI Card – User Manual
RME Madiface ExpressCard
The Mytek DIO MADI card can directly interface
with RME's HDSPe Madiface ExpressCard. There are
many advantages to using the Madiface ExpressCard
such as:
•
Full use of the PCI Express bus
•
High track count mobile solution
•
Low latency operation with RME's robust
drivers and TotalMix cue mixing software
•
Use of an adapter allows the card to be used
on a desktop system
The breakout box can be bypassed by directly
connecting the Madiface to the MADI DIO card. The
connection is made with a standard 6 pin FireWire
cable, but the signal does not use the FireWire
protocol. To avoid the risk of damaging the card,
please do not connect a FireWire signal to the
Madiface port on the DIO card or on the Madiface
ExpressCard itself.
Multiple Converter Configurations
MADI is capable of carrying 64 channels of I/O over
BNC, Optical, or through RME's proprietary
Madiface port. You can chain multiple converters
together using any combination of the three. The
following diagrams will detail how to connect the
signal lines and jumper settings.
