MADI Card Connectors
All outputs of the DIO MADI card are simultaneous. 7
and 8 DipSwitch positions are used to select inputs.
1. Opto IN
To use optical input set the 7 th and 8 th DipSwitch
positions both to ON.
2. BNC IN
To use BNC input set the 7 th DipSwitch position to
OFF and 8 th to ON. BNC connectors are used to
transmit MADI signal, do not connect to them
Wordclock signal.
3. Madiface RME
To use RME Madiface set the 7 th and 8 th DipSwitch
positions both to OFF. Madiface connector is
compatible with RME Madi, do not connect it to
FireWire (IEEE 1394) signal.
Other settings
4 th DipSwitch position is used to change format of
channels. There are two modes available:
•
At frequency of 44.1 and 48 kHz 4 th DipSwitch
OFF – 64 channels, ON – 56 channels.
•
At frequency of 88.2 and 96 kHz 4 th DipSwitch
OFF – 32 channels, ON – 28 channels.
•
At frequency of 176.4 and 192 kHz 4 th DipSwitch
OFF – 16 channels, ON – 14 channels.
Note!
When connecting or
disconnecting optical
connectors an output
noise can appear. To
prevent this you
should first connect
the optical connector
and then select the
card.
www.mytekdigital.com Page: 13/24
