Mytek DIO MADI Card – User Manual
5
th
DipSwitch position is responsible for the selection
frame type. At 44.1 and 48 kHz frame type 48k is used
only. At 88.2 and 96 kHz frame type 48k and 96k can be
used, and at 176.4 and 192 kHz frame type 48k is used
only.
Signal routing
The DIO MADI card works in both DIOCARD1 and
DIOCARD2 slots.
If ADC (Source To Digital Out) is set to MADI
(DIOCARD1 or DIOCARD2), then the signal incoming to
the card is routed to all available digital outputs
(AES/EBU or second card plugged in to the converter).
If ADC (Source To Digital Out) is set to Analog or
AES/EBU, then those 8 channels are routed to the selected
MADI channels (DipSwitch 1-3).
If DAC (Source To Analog Out) is set to MADI
(DIOCARD1 or DIOCARD2), then the incoming signal to
the card is routed to the analog outputs.
All connected devices
must operate at
identical frequencies,
the same formats, and
the same Frame set.
