Receptor v1.3 Release Notes 41 Muse Research, Inc.
Assigning an output from an instantiated plugin to feed audio into a channel
You can instantiate a multi-out plugin on one channel, then use its different outputs to feed audio into additional
Receptor channels. The following example discusses how to do this for Kompakt, though any multi-out plugin
will work identically.
First, instantiate a multi-out plugin on a Receptor channel:
1 Press the top display knob and rotate it to select Receptor CH 1.
2 Press the SOURCE button on Receptor’s front panel.
3 Make sure the Source parameter is showing on the top line of the LCD and rotate the bottom display knob
to select a multi-out plugin, such as Kompakt.
4 Press the bottom display knob to instantiate the plugin.
By default, the first pair of plugin outputs will be routed through this channel. If you wish to have a different set of
outputs feed the channel, use the Output:Plugin parameter, discussed previously.
Next, assign an output from that instantiated plugin to feed audio into a different Receptor channel:
5 Press the top display knob and rotate it to select Receptor CH 2.
6 If it’s not already selected, press the SOURCE button on Receptor’s front panel.
7 Make sure the Source parameter is showing on the top line of the LCD and rotate the bottom display knob
until you see the Source:Plugin Feed choices at the end of the list.
0 1 S o u r c e : P l u g i n F e e d < >
III III K o m p a k t - C H 1
The Plugin Feed sources all have the following naming convention:
-
8 When Kompakt-CH 1 is displayed, press the bottom display knob to select it.
By selecting this, you are telling Receptor that you want it to use, as a sound source, an audio output from the Kompakt
plugin that’s instantiated on Receptor Channel 1.
9 You’ll next see the Output:Plugin Feed parameter, which you use to tell Receptor which of Kompakt’s audio
outputs you wish to use as a sound source for this channel.
0 1 O u t p u t : P l u g i n F e e d < >
III III K o m p a k t 1 / 2
10 Since, by default, you assigned Kompakt 1/2 to Ch 1 (the channel used to instantiate the plugin), rotate the
bottom display knob to select a different output pair to feed this channel.
0 1 O u t p u t : P l u g i n F e e d < >
III III K o m p a k t 3 / 4
11 Press the bottom display knob to apply your selection.
The end result of all this is that Kompakt is instantiated on CH 1 and its 1/2 output pair feeds that channel, while its 3/4
output fair feeds Receptor CH 2.
