page 39 of 40 rev 1.4.2 041409 Millennia Media HV-3R

AD-R96 Specifications

Dynamic Range

mic preamp plus A/D Converter

> 110dB

Total Harmonic Distortion + Noise

mic preamp plus A/D Converter

< .001%,

Frequency Response

44.1 kHz
48 kHz
88.2 kHz
96 kHz

-0.5 dB @ 4Hz and 21.5kHz
-0.5 dB @ 4Hz and 23.4kHz
-0.5 dB @ 4hZ and 42.0kHz
-0.5 dB @ 4Hz and 25.8kHz


Full Scale Output Level


+24 dBu

Common Mode Rejection Ratio

Better than analog stage

IMD SMPTE 4:1 60 Hz, 7kHz

<.003%

Interchannel Crosstalk

20 kHz @ 45 dB gain and Full Scale Output

-88 dB


Maximum Non-harmonic Spurious Tones


Better than -140 dB


Intrinsic Jitter

20Hz-20kHz @ 48kHz

50 pS RMS typical


External Clock Lock Range


32-96 kHz

all measurements with HV-3D in circuit
Millennia Media, Inc. reserves the right to change specifications, delivery and pricing without notice

HDOE Output Expander Specifications

Frequency Response

+0 / -3 dB

sub 3 Hz to beyond 300 kHz

Noise

60 dB Gain, 10 Hz - 30 kHz, Inputs common

-133 dB EIN

Total Harmonic Distortion + Noise

35 dB Gain, 10 Hz - 20 kHz bandwidth, +27 dBu Out

< .001%, Typ. < .0005% (< 5 ppm)

Intermodulation Distortion

(50 Hz & 7 kHz) 35 dB Gain, +27 dBu Out

< .0009%

Phase Response

35 dB Gain, 50 Hz - 20 kHz bandwidth, +27 dBu Out

< 2 degrees deviation

Common Mode Rejection Ratio

35 dB Gain, 10 Hz - 20 kHz bandwidth, 100 mV C.M.

> 65 dB, Typ > 85 dB

Slew Rate

35 dB Gain, +27 dBu Out

> 25 Volts per microsecond

Maximum Output Level

20 Hz - 40 kHz

+32 dBu

Output Attenuation

13.5 dB internal jumper selectable

Output Impedance

24.3 Ohms (x2)

Millennia Media, Inc. reserves the right to change specifications, delivery and pricing without notice
