9

©

www.mfdigital.com

USB SD Platform 5000 series

2.5

System Information

This feature will show the duplicator system information which includes the controller
model number and the software version.


2.6

Utilities

2.6.1 FAT16/32 Formatting


The purpose of this function is to perform FAT flash formatting of the USB/SD Cards.
Plug the USB/SD into the slot and press OK, the system will start the auto detect
capacity function and format according to the card’s capacity.

If USB/ SD format is already FAT16 or FAT32, the format function won’t change
original format.

If USB/ SD format is un-FAT format, i.e. NTFS, Linux or FAT multi-partition

.

The

system will

format according to capacity. When the capacity is above 2GB the system

will format to FAT32 and if the capacity is below 2GB the system will automatically
format to FAT16.

During the formatting process the user

can press the

buttons to

check each Flash Card’s formatting status, progress and information.


The source port (port#1) will not execute any formatting.

2.6.2 Measure Speed


This function will measure the Flash “read” and “write” speed. The speed check
function will not delete any data from the Flash.

Plug the SD/USB into the slot and select the Measure Speed function then press ok
to start the process. The user can also use the

buttons to see the exact

“Read” and “Write” speed from each port

Controller Model Number

System Firmware
