7
© www.mfdigital.com USB SD Platform 5000 series
illuminate.
During the copying process each card slot’s green LED will flash, do not
remove the card while the unit is copying.
When there is a big difference in the target and source cards capacity (e.g.
copying from 1GB to 4GB), an error may occur with the target cards
capacity and format. It is strongly recommended that the capacity of the
target and source cards, are in close range of each other.
2.2
Asynchronous Copy
Plug in the source flash and press OK, and then the system will start to read the
source content and transfer it into system’s buffer. It will then immediately start to
copy, once a target flash card has been plugged in.
During the copying process each card slots green LED light will flash. When copying
has finished, the green LED will stop flashing and remain solidly lit. Then you can
take out the card and put in another new flash card. The Red LED will only be lit
when a copying error has taken place
You can take out cards which have finished copying and plug in replacement flash
cards, and the unit will continue to copy. When the copying has finished the LCD
display shows whether the copying has succeeded or failed. It also shows the
quantity that was copied and the time that it took.
During the asynchronous copy process you can press the buttons to
check each Flash Card’s copying status and progress.
When there is an error (i.e. the Red LED is on) you can also press the
buttons to check each Flash Card’s status.
For example
： ： ： ：
Amount Completed
Quantity Copied
Quantity of flash cards copying
Port no. 5 status
Total size
