MAX11300PMB1 Peripheral Module and Munich (USB2PMB1) Adapter Board Quick Start Guide
1. Required Equipment
• PC with Windows ®
OS (Windows XP
®
, Windows Vista, Windows 7, Windows 8
and Windows 8.1) with one USB port
• MAX11300PMB1# board
• Munich (USB2PMB1#) board
• USB Type A to Mini B Cable
• Munich Software GUI
2. Overview
This document explains how the MAX11300PMB1 featuring the MAX11300 20-port
programmable mixed-signal I/O device interfaces with the Munich (USB2PMB1#)
adapter board and how to use the GUI.
The MAX11300PMB1 peripheral module provides the necessary hardware to interface
the MAX11300 20-port device to any system that utilizes Pmod™-compatible expansion
ports configurable for SPI communication (Figure 1). MAX11300 configuration software
is a design tool used to create the configuration bit stream that is downloaded to the
MAX11300 through the Munich adapter board (
Figure 2 ).
Refer to the MAX11300 IC data sheet for detailed information regarding operation of the
IC and to the USB2PMB1 adapter board data sheet for detailed information regarding
the Munich board and GUI. Refer to the MAX11300/MAX11301 PIXI™ Configuration
Software User Guide for detailed information using the design tool.
The Munich GUI and the USB2PMB1 adapter board are referred to as Munich
throughout this document.
