58 EMB-M3 User`s Manual
Onboard Parallel Port
This item allows you to determine onboard parallel port controller I/O
address setting.
The choice: 378/IRQ7, 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
Select an operating mode for the onboard parallel (printer) port. Select
Normal, Compatible, or SPP unless you are certain your hardware and
software both support one of the other available modes.
The choice: SPP, EPP, ECP, ECP+EPP, Normal.
EPP Mode Select
Select EPP port type 1.7 or 1.9.
The choice: EPP1.7, 1.9.
ECP Mode Use DMA
Select a DMA channel for the parallel port for use during ECP mode.
The choice: 3, 1.
PWRON After PWR-Fail
The choice: Off, On, Former-Sts .
Onboard Serial Port 3/Port 4/Port 5/Port 6
The choice: 4F8, 3F8, 2F8, 4E8, 3E8, 2E8, Disabled.
Serial Port 3/Port 4/Port 5/Port 6 Use IRQ
The choice: IRQ3, IRQ4, IRQ5, IRQ7, IRQ9, IRQ10.
Watch Dog Timer Select
The choice: Enable, Disabled.
