EMB-M3 User`s Manual 5
1 x PS2 Keyboard and 1 x Mouse connector on a stack-up
Dual Mini-DIN connector.
Two Internal RS-232 ports, COM5~COM6 are in
2x5/10-pin/2mm/pin-header. Pin9 can be powered by either
5V or 12V with a 3-pins jumper.
• Hardware Monitor:
83627HF integrated hardware monitor chip to monitor
Voltages, temperatures and FAN speed.
Temperature Monitor: CPU remote diode, one thermister
close to CPU socket, one thermister close to 83627HF chip.
One CPU FAN close to CPU socket. One system FAN close
to 83627HF chip.
• 10/100M Ethernet:
One RTL8100BL for 10/100M LAN.RJ45 connector with
Link/Act and Speed LED integrated.
Support Wake-on-LAN while ATX power supply is attached.
The LAN connector is RJ45+USBx2 combo connector on
rear panel.
• PIDE:
P IDE controller build in ICH4 support up to UltraDAM100.
One 40-pins Box header (2.54mm pitch) to support 3.5” HDD,
CDROM or DVD player.
One 44-pins Box-header (2m/m pitch) support 2.5” ATA
devices, Slim CD-ROM or DOM FlashDisk.
One CompactFlash-II socket on back side, shared with
Secondary IDE Channel. One 3-pins jumper/2mm to select as
Master or Slave device.
• Watchdog Timer:
The timeout interval and disable/enable selection can be
programmed in BIOS setup.
The timeout event will generate the RESET.
• COMS:
On-board RTC with 242 bytes of Battery-back CMOS RAM.
One 3-pins Jumper to clear CMOS data.
• Audio:
RealTek ALC201A AC97 Audio chip on-board.
Two stack-up 3.5mm Audio-Jack on rear for Audio
Line-OUT and MIC.
One CD-ROM Audio-In 4-pins connector on-board.
