54 EMB-M3 User`s Manual
Integrated Peripherals
Phoenix – AwardBIOS CMOS Setup Utility
Integrated Peripherals
OnChip IDE Device [Press Enter]
Onboard Device [Press Enter]
SuperIO Device [Press Enter]
Onboard Serial Port 3 [3E8]
Serial Port 3 Use IRQ [IRQ4]
Onboard Serial Port 4 [2E8]
Serial Port 4 Use IRQ [IRQ3]
Onboard Serial Port 5 [4F8]
Serial Port 5 Use IRQ [IRQ4]
Onboard Serial Port 6 [4E8]
Serial Port 6 Use IRQ [IRQ3]
Watch Dog Timer Select [Disabled]
Item Help
Menu Level
↑↓←→: Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit F1:General Help
F5:Previous Values F6:Fail-safe defaults F7:Optimized Defaults
OnChip IDE Device
Phoenix – AwardBIOS CMOS Setup Utility
OnChip IDE Device
On-Chip Primary PCI IDE [Enabled]
IDE Primary Master PIO [Auto]
IDE Primary Slave PIO
[Auto]
IDE Primary Master UDMA [Auto]
IDE Primary Slave UDMA [Auto]
On-Chip Secondary PCI IDE
[Enabled]
IDE Secondary Master PIO [Auto]
IDE Secondary Slave PIO [Auto]
IDE Secondary Master UDMA [Auto]
IDE Secondary Slave UDMA [Auto]
IDE HDD Block Mode [Enabled]
Item Help
Menu Level
↑↓←→: Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit F1:General Help
F5:Previous Values F6:Fail-safe defaults F7:Optimized Defaults
