Chapter 4: LANVIEW LEDs
Page 4-2 BRIM-A6 User’s Guide
4.2 APIM LEDs
Table 4-2 describes each of the APIM LEDs.
Table 4-2 APIM LEDs
LED Definition
LNK
(Link) Green - Have link.
Off - No link.
STS
(Status) Green - APIM OK.
Red - Fault with media. In most
cases, the APIM automatically
corrects this condition without
interrupting operations. If the LED is
red and remains red, contact
Cabletron Systems Technical
Support.
