Chapter 3: Local Management
Page 3-10
BRIM-A6 User’s Guide
3.3.3 Using BRIM-A6 Setup Screen Commands
To select BRIM-A6 Setup screen commands, perform the following steps:
1. Use the arrow keys to highlight a BRIM-A6 Setup screen command.
2. Press ENTER, LM executes the selected command.
3.3.4 Accessing the BRIM-A6 Add/Delete Entry Screen
To access the BRIM-A6 Add/Delete Entry screen from the BRIM-A6
Setup screen, perform the following steps:
1. Use the arrow keys to highlight the Add/Delete Entry selection at the
bottom of the BRIM-A6 Setup screen.
2. Press ENTER, the BRIM-A6 Add/Delete Entry screen Figure 3-3
appears.
Figure 3-3
The BRIM-A6 Add/Delete Entry Screen
Local Management
Flash Image Version: XX.XX.XX
BRIM-A6 ADD/DELETE ENTRY
VPI
VCI
AAL Type
Encapsulation Type
0
0004
[5]
[VC Mux Bridged 802.3 ]
ADD/MODIFY
(DELETE)
RETURN
131106
