Chapter 3: Local Management
Page 3-6 BRIM-A6 User’s Guide
3.2.4 Adding PVCs to the Connection Tables Screen
To add PVCs to the Connection Tables screen, perform the following
steps:
1. Use the arrow keys to highlight the Mode field.
2. Press ENTER to select ADD.
3. Use the arrow keys to highlight the VPI field.
4. Enter the VPI number you want to add and press ENTER.
5. Use the arrow keys to highlight the VCI field.
6. Enter the VCI number you want to add and press ENTER.
7. Use the arrow keys to highlight the SAVE command at the bottom of
the screen.
8. Press ENTER. The “ADDING CHANNELS” message appears
indicating that LIM has saved all changes to memory.
3.2.5 Deleting PVCs from the Connection Tables Screen
To delete PVCs from the Connection Tables screen, perform the
following steps:
1. Use the arrow keys to highlight the Mode field.
2. Press ENTER to select DELETE.
3. Use the arrow keys to highlight the PVC you want to delete.
4. Use the arrow keys to highlight the SAVE command at the bottom of
the screen.
5. Press ENTER. The “DELETING CHANNELS” message appears
indicating that LIM has saved all changes to memory.
