Chapter 3: Local Management
Page 3-12 BRIM-A6 User’s Guide
3.3.6 BRIM-A6 Add/Delete Entry Screen Commands
The following commands appear at the bottom of the BRIM-A6
Add/Delete Entry screen:
Add/Modify
This command lets you add or modify PVCs to the BRIM-A6 Add/Delete
Entry screen.
Delete
This command lets you delete PVCs from the BRIM-A6 Add/Delete
Entry screen. This command appears only after you add or modify an
existing PVC.
Return
This command lets you exit from the BRIM-A6 Add/Delete Entry screen.
3.3.7 Adding a PVC
To add a PVC, perform the following steps:
1. Use the arrow keys to highlight the VPI field and enter a VPI value
from 0-3.
2. Use the arrow keys to highlight the VCI field and enter a VCI value
from 0-1023.
3. Use the arrow keys to highlight the AAL Type field and press the
SPACE bar until the desired AAL Type appears.
4. Use the arrow keys to highlight the Encapsulation Type field and press
the SPACE bar until the desired Encapsulation Type appears.
5. Use the arrow keys to highlight the ADD/MODIFY command.
6. Press ENTER. The “ENTRY ADDED” message appears at the top of
the screen indicating that LM has added the PVC.
NOTE
LM automatically saves entries when you exit the field.
