19
E.
Now the dot sight should be zeroed.
Make sure to lock both elevation and
windage knobs.
Single Dot Reticle
Circle Dot Reticle
Illustration
Specs
Dot size: about 4 MOA
Dot size: about 4 MOA
Circle Dia.: about 62 MOA
F. Different Dot Sight Reticles:
Note: Depending on your models, your dot sight may come with
one of the following reticles:
