3 preparing the computer for disassembly, 3 preparing the computer for disassembly –4 – Compaq 1500 User Manual
Page 96
5–4
Maintenance and Service Guide
Removal and Replacement Procedures
5.3 Preparing the Computer for
Disassembly
Perform the following steps before disassembling the computer:
1. Turn off the computer.
2. Disconnect the AC adapter and all external devices.
Section
Description
# of Screws Removed
5.16
TouchPad and TouchButton
4 on TouchPad models
5 on Dual Stick models
5.17
Display release assembly
2
5.18
Charger board
3
5.19
Speaker assembly
0
5.20
Top cover
5
5.21
Fan
0
5.22
System board
7
5.23
Modem cable
1
Disassembly Sequence Chart
(Continued)
279372-001.book Page 4 Friday, July 19, 2002 11:50 AM
