18 charger board, 18 charger board –46 – Compaq 1500 User Manual
Page 138
5–46
Maintenance and Service Guide
Removal and Replacement Procedures
5.18 Charger Board
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the palm rest (Section 5.14).
3. Remove the three TM2.5 × 5.0 screws 1 that secure the
charger board to the base enclosure (Figure 5-37).
4. Lift the front edge of the charger board shield 2 until it clears
the base enclosure, then slide the shield forward to remove it.
Charger Board
Spare Part Number Information
Charger board
The charger board shield is included in the Miscellaneous
Plastics/Hardware Kit, spare part number 285541-001.
285525-001
279372-001.book Page 46 Friday, July 19, 2002 11:50 AM
