20 top cover, 20 top cover –49 – Compaq 1500 User Manual
Page 141
Removal and Replacement Procedures
Maintenance and Service Guide
5–49
5.20 Top Cover
✎
When replacing the top cover, ensure that the microphone is
removed from the old top cover and installed on the new top
cover.
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a.
LED cover (Section 5.9)
b.
Keyboard (Section 5.10)
c.
Heat spreader (Section 5.11)
d. Display (Section 5.13)
e.
Palm rest (Section 5.14)
2. Turn the base enclosure bottom side up with the rear panel
facing forward.
Top Cover
Spare Part Number Information
Top cover
285535-001
279372-001.book Page 49 Friday, July 19, 2002 11:50 AM
