CY7C1347G
Document #: 38-05516 Rev. *F Page 12 of 22
Switching Waveforms
Figure 5. Read Cycle Timing
[16]
tCYC
t
CL
CLK
ADSP
t
ADH
t
ADS
ADDRESS
t
CH
OE
ADSC
CE
tAH tAS
A1
tCEH tCES
GW, BWE,
BW [A:D]
Data Out (Q) High-Z
tCLZ
tDOH
tCO
ADV
tOEHZ
tCO
Single READ BURST READ
tOEV
tOELZ tCHZ
ADV
suspends
burst.
Burst wraps around
to its initial state
tADVH tADVS
tWEH tWES
tADH tADS
Q(A2) Q(A2 + 1) Q(A2 + 2) Q(A1) Q(A2) Q(A2 + 1) Q(A2 + 3)
A2 A3
Deselect
cycle
Burst continued with
new base address
DON’T CARE UNDEFINED
Note
16. In this diagram, when CE is LOW, CE
1
is LOW, CE
2
is HIGH, and CE
3
is LOW. When CE is HIGH, CE
1
is HIGH, CE
2
is LOW, or CE
3
is HIGH.
