Product Description
Maintenance and Service Guide
1–33
4
Vents
Allow airflow to cool internal components.
Ä
CAUTION: To prevent damage, the computer shuts down if an
overheating condition occurs. Do not block the cooling vent.
Avoid placing the computer on a blanket, rug, or other flexible
surface that may cover the vent area.
5
USB connectors (2)
Connect USB devices.
6
Fan
Provides airflow to cool internal
components.
7
S-Video connector
Connects a television, VCR, camcorder, or
overhead projector.
8
External monitor
connector
Connects an external monitor or overhead
projector.
9
External
keyboard/mouse
connector
Connects an optional full-sized keyboard or
mouse. An optional splitter/adapter allows
both an external keyboard and mouse to be
used at the same time.
10
Parallel connector
Connects a parallel device.
11
RJ-45 network jack
Connects the network cable. A network
cable is not included with the computer.
12
RJ-11 modem jack
Connects the modem cable to an internal
modem. A modem cable is included with
internal modem models.
13
Security cable slot
Attaches an optional security cable to
the computer.
14
PC Card eject button
Ejects a PC Card from the PC Card slot.
15
PC Card slot
Supports a 32-bit (CardBus) or 16-bit
PC Card.
16
Diskette drive
Accepts diskettes.
Table 1-6
Rear Panel and Left Side Components
(Continued)
Item
Component
Function
