5–50
Maintenance and Service Guide
Removal and Replacement Procedures
5.20 Top Cover
✎
When replacing the top cover, ensure that the microphone is
removed from the old top cover and installed on the new top
cover.
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a.
LED cover (Section 5.9)
b.
Keyboard (Section 5.10)
c.
Heat spreader (Section 5.11)
d. Display (Section 5.13)
e.
Palm rest (Section 5.14)
2. Turn the base enclosure bottom side up with the rear panel
facing forward.
Top Cover
Spare Part Number Information
Top cover
285535-001
