8
50. Align and install the Bpillar trim panel clips (3) rear
ward and into the quarter trim panel.
51. Push the trim panel (2) down into the body (4) using
hand pressure until all clips are seated.
52. Align and install the trim panel to the body slots (1) on
the Bpillar. Snap into place using hand pressure.
53. Feed the seatbelt webbing through the Bpillar trim (2).
Slide the belt adjuster to the top position.
54. Install the trim by sliding down and into the Bpillar
lower trim.
55. Align the 4way locator and seat the Bpillar trim to the
body.
56. Install the screw and screw cover.
57. Position the seat back to its original position.
CAUTION: When installing the cowl trim cover make sure not to damage the body plugs, around the sill area. If
damage occurs to the body plugs, replace with new plugs. Failure to replace a damaged body plug results in a
water leak to the floor area of the vehicle.
