9
54. Install the 40% seat section (4) over the stud and seat
bracket and install the seat bracket bolts (6).
55. Tighten the seat bracket bolts (6) to 46 N∙m (34 ft.
lbs.).
56. Install the nut (5).
57. Tighten the nuts (5 and 3) to 80 N∙m (60 ft. lbs.).
58. Position the seat backs (3) up and latch.
59. Install the belt buckles (1) and install the bolt (2).
60. Tighten the buckle bolt to 66 N∙m (49 ft. lbs.)
61. Install the bolts (4) and tighten to 80 N∙m (59 ft. lbs.)
62. Place the seat cushion into the vehicle and tuck the
rear of the cushion (1) up under the seat belt buckles
and rear seat back.
63. Lower the front of the cushion (3) down and install the
bolts (2).
64. Tighten the bolts to 80 N∙m (60 ft. lbs.).
Oct 16, 2009 K6860899 Rev. 1
