© 2005 Jaypro Sports Equipment JSL-Inst034 Rev D 04-26-2010 3 of 14
*** To Be Assembled by Qualified Personnel Only ***
Important:
1) Unpack all parts and check against parts list to ensure that all parts have been
included.
2) Inspect all parts for damage. Report any damages to the trucking company.
General Notes:
• There are two different 5/16” x 1-1/4” carriage bolts, galvanized and zinc plated. The
galvanized 5/16” x 1-1/4” carriage bolts (item 23) and nuts (item 30) are used to clamp the pipe
clamps. The zinc plated (ZP) 5/16” x 1-1/4” carriage bolts (item 18) and flange nuts (item 26)
are used to anchor the seat planks.
• Call Jaypro for pricing and scheduling of a field maintenance visit from one of our highly
trained specialists if you are unwilling or unable to perform the regular maintenance yourself.
This enclosure will ensure no exposed seat is higher than 30” and comes with a footboard and
kickback to complete the upgrade.
Required Tools:
- 1/2” and 9/16” Box Wrench
- 1/2” and 9/16” Socket Wrench
- Flat blade Screwdriver
- 3/16”
Allen Wrench
- 5/16” Allen Wrench
- Electric Drill with 3/8” bit & Philip Screwdriver
- Rubber Mallet
- Needle Nose Pliers
Installation Instructions
a) Install Riser Planks and Additional Foot Planks:
To bring your bleacher up to code, a double foot plank and back riser plank are required on the
fourth and fifth rows. The existing foot planks on the fourth and fifth rows will need to be removed
and repositioned to allow room for double planking.
1) Remove all hardware anchoring both fourth and fifth row foot planks. To improve access
you can also remove the fifth row seat plank at this time (removal of fifth row seat plank
will be required when installing the guardrail back supports (see step b).
2) Lay out both foot planks (9) on the fourth row support frame. New holes will need to be
drilled if they don’t already exist for the double planks. On one of the end frames measure
out the required hole spacing. Drill the necessary 3/8” holes in each of the frame supports.
3) Install the end caps on the new planks, if not already installed (see step c).
4) Install the double foot planks using the hardware shown in Detail A.
5) Install the fourth row riser plank (9) by centering it vertically in the space between the foot
plank and bottom edge of the seat plant. Drill one 3/8” hole, centered on the upper slot, in
each vertical frame member. Anchor the riser plank using the hardware shown in Detail A.
6) Repeat steps 2 thru 5 for the fifth row.
