© 2005 Jaypro Sports Equipment JSL-Inst034 Rev D 04-26-2010 2 of 14
Important Notes
• Follow all warning signs and labels on equipment. Use of this equipment other
then intended, may be hazardous.
• Before each use check equipment for proper connecting hardware and structural
integrity. Replace damaged or missing hardware immediately.
• For safe operation and continued high performance from this equipment,
inspection and maintenance must be performed at the beginning and end of each
season.
Part List
Item # Quantity Part Number Part Description
1 4 GR-RP GUARDRAIL BACK SUPPORT
2 2 BLCH5CUE-GRSP GUARDRAIL SIDE SUPPORT
4 2 BLCH-5-GR-N1 1.90” x .109” WALL x 55-7/8” LONG PIPE
3 4 BLCH-5-GR-N2 1.90” x .109” WALL x 60” LONG PIPE
5 2 BLCH-5-GR-N3 1.90” x .109” WALL x 67” LONG PIPE
6 2 BLCH-5-GR-N4 REAR RAIL PIPES15’ / 21’ (ONE W/ & W/O HOLES)
7 1 BLCH5CUE-CHN PRE-FABRICATED CHAIN LINK PANEL GALVANIZED
8 2 BLCH-5-SC PRE-FABRICATED 5’ CHAIN LINK FENCE GALVANIZED
9 4 AR5043/AR5052 STADIUM SEAT PLANK 1 ½” x 9 ½” x 15’or 21’
10 4 AF5010 ADJUSTABLE ELBOW
11 2 AF5011 CORNER FITTING
12 2 SF177A TEE FITTING
13 2 SF186 ADJUSTABLE TEE
14 80 AF116 ALUMINUM FENCE RAIL TIE
15 26 AF56 BRACE PIPE CLAMP
16 56 AR5044 BOLT CLIP W/ SLOTS FOR 5/16” CARRIAGE BOLT
17 26 EC0023 SOFT VINYL CAP
18 44 HB5054 5/16”-18 x 1-1/4” SHORT CARRIAGE BOLT, ZP (PLANKS)
19 8 EP0018 2” x 2” BLACK SQUARE TUBE CAP
20 4 EP0019 2” ROUND CAP
21 16 EP0025 ½” HOLE PLUGS
22 8 HB4078 5/16”-18 x 1-1/2” CARRIAGE BOLT, ZP (BACK SUPPORT)
23 18 HB196 5/16”-18 x 1-1/4” CARRIAGE BOLT GALV. (CLAMPS)
24 8 HB5030 5/16”-18 x 3" CARRIAGE BOLT, ZP (RISER PLANKS)
25 8 HS4089 5/16”-18 x 3” PAN HEAD SLOT SCREW, ZP (SUPPORTS)
26 70 HN5046 5/16”-18 FLANGE NUT, ZP
27 8 HW2049 5/16” FLAT WASHER SAE, ZP
28 8 AR5045 END CAP 9 ½” FOR ALUMINUM SEAT PLANKS
29 16 HS5035 #8 x ½” PAN HEAD PHILIP SCREW SELF DRILL, ZP
30 18 HN807 5/16”–18 GALVANIZED HEX NUT
31 4 HS292 3/8”-16 HEX HEAD CAP SCREW, ZP (LOWER RAIL PIPE)
32 4 HN5042 3/8”-16 FLANGE HEX NUT
