Dimensions

Appendix

1.16(29.5)

6.73(171.0)

6.89(175.0)

15.20(386.0)

15.16(385.0)

7.25(184.0)

1.43(36.2)

0.04(1.0)

1.31(33.2)

7.13(181.2)

4.16(105.6)

3.45(87.6)

12.09(307.0)

6.22(158.0)

3.92(99.6)

2.09(53.0)

12.64(321.0)

6.25(158.8)

3.92(99.5)

0.87(22.2)

3.21(81.5)

0.87(22.2)

0.39

2.43(61.6)

2.43(61.6)

3.05(77.5)

0.63(16.0)

7.48(190.0)

14.17(359.9)

4.10(104.2)

4.25(8.0)

4.25(108.0)

0.39(10.0)

4.51(114.5)

4.95(125.8)

4.25(107.9)

3.23(81.9)

1.27(32.2) 2.55(64.7)

Unit: inch(mm)

Screw Holes for Ceiling Mount

Screw: M4

Depth: 0.63(16.0)
