CY62147DV18
MoBL2™
Document #: 38-05343 Rev. *B Page 7 of 11
Notes:
17. Data I/O is high impedance if OE = V
IH
.
18. If CE goes HIGH simultaneously with WE = V
IH
, the output remains in a high-impedance state.
19. During this period, the I/Os are in output state and input signals should not be applied.
Switching Waveforms (continued)
t
HD
t
SD
t
PWE
t
SA
t
HA
t
AW
t
WC
DATA I/O
ADDRESS
CE
WE
OE
t
HZOE
DATA
IN
NOTE
Write Cycle No. 1 (WE Controlled)
[13, 17, 18]
19
BHE/BLE
t
BW
t
SCE
t
HD
t
SD
t
PWE
t
HA
t
AW
t
SCE
t
WC
t
HZOE
DATA
IN
CE
ADDRESS
WE
DATA I/O
OE
NOTE 19
Write Cycle No. 2 (CE Controlled)
BHE/BLE
t
BW
[13, 17, 18]
t
SA
