Chapter 1 Cisco 7200 VXR Product Overview
Functional Overview
Chassis Slot and Logical Interface Numbering
In the Cisco 7200 VXR routers, the port-adapter-slot-number is the chassis slot in which a port adapter
is installed, whereas the logical-interface-number is the physical location of the interface port on a port
adapter.
Port adapter slots in the Cisco 7200 VXR routers are numbered from left to right— slot 1 through slot 4
in the Cisco 7204VXR (see
) and slot 1 through slot 6 in the Cisco 7206VXR (see
). Port adapter slot 0 is always reserved for the Fast Ethernet port on the I/O controller—if
present.
Figure 1-31
Port Adapter Slot Numbering—Cisco 7204VXR
1
Blank port adapter
4
Port adapter slot 3
2
Port adapter slot 4
5
Port adapter slot 1
3
Port adapter slot 2
6
Port adapter slot 0 (Reserved for the Fast
Ethernet port on the I/O controller. With the
NPE-G1 or NPE-G2 and the Port Adapter
Jacket Card installed, the slot becomes port
adapter slot 5.)
2
ETHERNET-10BFL
EN
RX
0
1
2
3
4
TX
RX
TX
RX
TX
RX
TX
R
X
TX
0
4
1
3
5
6
EN
0
7
1
2
3
4
5
6
SERIAL-EIA/TIA-232
Cisco 7200
SERIES
MII
EN
RJ45
EN
RJ45
LINK
1O PWR
OK
R
J-45
C
PU
R
E
SE
T
FAST ETHERNET INPUT/OUTPUT CONTROLLER
ENABLED
PCMCIA
EJECT
SLOT 0
SLOT 1
FE MII
ENABLED
MII
LINK
RJ45
FAST ETHERNET
0
84540
1
2
3
4
5
6
